Description of CYCJET C703 Economical Inkjet Printer / Inkjet Logo
Printer
C703 is a "piezo inkjet" printer (PIJ). This technology combines
the advantages of large format inkjet printer and high-resolution
inkjet coding. It can print graphics, text and GS1-128 compliant
barcodes without the need to stick labels on the boxes.
Its double heads design makes it as a wide format inkjet printer
and is very popular in all kinds of packages printing.
Compared with label technology, the use of PIJ inkjet printer can
reduce the overall overall cost and reduce waste. This will help
improve overall operational efficiency and help manufacturers
achieve sustainable development goals. Coupled with CYCJET's
self-developed non-hazardous vegetable oil-based ink, manufacturers
can not only obtain high-quality labels, but also greatly reduce
the negative impact on the environment.
When designing and creating C703, we are not only committed to
developing improvements that surpass our competitors, but we also
strive to retain the features of our traditional products that have
benefited many customers. The large-capacity ink tank can reduce
the frequency of ink replenishment in high-speed production without
stopping the machine. Multiple nozzles supplied by a single ink
unit can provide large-format printing layouts, and a C703
controller can also achieve multi-sided coding of boxes.
Printing character: 2mm to 215.4mm;
Multi-line printing
Printing speed:40m/min;
Printing random code, database, batch barcode, QR code;
Character direction: 90°, 180°, 270° rotation;
High-Resolution LED display, max logo 1024x512 DPI;
No need connect PC, input message by keyboard directly;
Max storage capacity:1000PCS;
Resolution: 180dpi
Technical Parameter of CYCJET C703 Economical Inkjet Printer / Inkjet Logo Printer:
| Print Height | 1-215.4mm |
| Print Spacing | It is subject to the printing content & ink type |
| Print Lines | The lines unlimited within Max height 71.8mm. |
| Print Speed | 40m/min (Cross direction resolution 100DPI) |
| Print Resolution | Resolution height is 200DPI; Cross direction resolution 100-400DPI
can be adjustment |
| Print Fonts | The built-in various font, and horizontal bar,vertical
bar,dot-matrix,bold font can be free change. |
| Print Content | Real Date, Real time, Photo, Letter, Shift group, Serial number,
Batch number, Lot number Barcode and 2D code can be free print. |
| Print Direction | Upward printing, downward printing, side printing(360°direction
printing) |
| Font library | Standard font library are Chinese & English, and The
Spanish,Portuguese,Arabic font library can be optional |
| Operator Interfaces | Image-style & Chinese or English ( Spanish,Portuguese,Arabic)menu,
What you see is what you get. |
| Memory Function | More than 1000pcs text can be storage |
| Ink Type | Ink is originally from UK. There are Solvent-based ink (machine
should be regular maintenance); Invisible ink (Machine should be
regular maintenance); Oil-based ink (machine maintenance free). |
| Ink Color | Black, Red,Yellow, Blue,Green,white, etc… |
| Protection level | Not suitable for high dust, high humidity working environment |
| Powder | AC220V±10%, 50-60HZ, 5 W; |
Humidity Range
Temperature Range | 10-90% Non-condensing
5-40°C |
| Others | No need connect external compressed air, and no need thinner (i.e.
solvent) |
